BE0803 - 229 Micron Photo Chemically Etched Screen - Hole Profile B

SKU: BE0803-S


Product Description

  • Burr-free precision etched stainless steel screens
  • Perforated area of panels measures 18" x 21" minimum
  • Thickness tolerance is +/- 10%
  • Hole size tolerance is +/- 15% of material thickness
  • Hole Profile A = Cone Hole
  • Hole Profile B = Etched equally from both sides

Nominal Specifications

Hole Profile: B

Hole Size (in): 0.009

Hole Size (microns): 229

Material Hardness: 1/4 hard

Open Area (Transmission): 26%

Orientation (alignment of holes to one another): 90

Steel Type: 316 SS

Thickness (in): 0.008
