Extruded Square

Plastic Square Mesh Netting

Extruded Plastic Diamond Mesh Netting for Industrial ApplicationsThe joint structure of Plastic Square netting is produced using reciprocating dies. Machine direction strands run the length of the roll and cross direction strands run the width of the roll. Joints are formed at the intersection and are not stacked one over the other as in diamond net mesh plastic netting.

Generally, the machine direction strand is thicker than the cross direction strand. The overall thickness of the netting is typically determined by the machine direction strand thickness. As a result of this joint configuration, plastic square netting usually has one side of the material that is smooth, that is, both the machine and cross strands are flush on the same plane, and one side that is "bumpy", where the machine direction strand has a higher profile than the cross strands.

Square mesh plastic netting is extruded in a wide range of configurations featuring:

  • Structural integrity
  • Apertures "locked" by fused joints
  • Smooth surface on one side
+ Color






+ Resin (material)



+ FDA Compliance



+ Thickness Range




+ Hole Size Inches Range




+ Open Area Range







XN6080 - 0.021" Square PP Mesh 0.014" Thickness, 37.5" width

XN6080 - 0.021" Square PP Mesh
0.014" Thickness, 37.5" width



XN6080 - 0.021" Square PP Mesh 0.014" Thickness, 30.59" width

XN6080 - 0.021" Square PP Mesh
0.014" Thickness, 30.59" width



XR6065 - 0.025" Square PP Mesh 0.014" Thickness

XR6065 - 0.025" Square PP Mesh
0.014" Thickness



XN6070 - 0.025" Square PP Mesh 0.014" Thickness

XN6070 - 0.025" Square PP Mesh
0.014" Thickness



XN3019 - 0.030" Square PP Mesh 0.036" Thickness

XN3019 - 0.030" Square PP Mesh
0.036" Thickness



XN5170 - 0.040" Square PP Mesh 0.019" Thickness

XN5170 - 0.040" Square PP Mesh
0.019" Thickness



XN3234 - 0.054" Square PP Mesh 0.019" Thickness

XN3234 - 0.054" Square PP Mesh
0.019" Thickness



XN1588 - 0.085" Square PP Mesh 0.05" Thickness

XN1588 - 0.085" Square PP Mesh
0.05" Thickness



XN1335 - 0.085" Square PP Mesh 0.069" Thickness

XN1335 - 0.085" Square PP Mesh
0.069" Thickness



XV1347 - 0.095" x 0.175" Square PE Mesh, 0.07" Thickness

XV1347 - 0.095" x 0.175" Square PE Mesh, 0.07" Thickness



XV1340 - 0.095" Square PE Mesh 0.07" Thickness

XV1340 - 0.095" Square PE Mesh
0.07" Thickness



XN2410 - 0.100" Square PE Mesh 0.050" Thickness

XN2410 - 0.100" Square PE Mesh
0.050" Thickness



XV1672 - 0.125" Square PE Mesh <br>0.038" Thickness

XV1672 - 0.125" Square PE Mesh
0.038" Thickness



XN1678 - 0.125" Square PP Mesh 0.035" Thickness

XN1678 - 0.125" Square PP Mesh
0.035" Thickness



XN1673 - 0.145" Square PP Mesh 0.035" Thickness

XN1673 - 0.145" Square PP Mesh
0.035" Thickness



XN2950 - 0.150" Square PP Mesh 0.048" Thickness

XN2950 - 0.150" Square PP Mesh
0.048" Thickness



XN2341 - 0.155" Square PE Mesh 0.055" Thickness

XN2341 - 0.155" Square PE Mesh
0.055" Thickness



XB0265 - 0.203" Square PE Mesh 0.059" Thickness

XB0265 - 0.203" Square PE Mesh
0.059" Thickness



XN0260 - 0.203" Square PP Mesh 0.059" Thickness

XN0260 - 0.203" Square PP Mesh
0.059" Thickness



XV1170 - 1/4" Square PE Mesh 0.08" Thickness

XV1170 - 1/4" Square PE Mesh
0.08" Thickness



XN5050 - 1/4" Square PE Mesh 0.095" Thickness

XN5050 - 1/4" Square PE Mesh
0.095" Thickness



XY5030 - 0.275" Square PE Mesh 0.095" Thickness

XY5030 - 0.275" Square PE Mesh
0.095" Thickness



XE5010 - 0.275" Square PP Mesh 0.121" Thickness

XE5010 - 0.275" Square PP Mesh
0.121" Thickness



XN5010 - 0.275" Square PP Mesh 0.121" Thickness

XN5010 - 0.275" Square PP Mesh
0.121" Thickness



+ Color






+ Resin (material)



+ FDA Compliance



+ Thickness Range




+ Hole Size Inches Range




+ Open Area Range
